Lg Air Conditioning MU2R15-UL0 Multi Room Heat Pump Inverter 2 Port 4Kw/14000Btu A+++ R32 240V~50Hz

SKU:PB-LG-UL0-MULTI-ROOM
0 reviews
£1,123.88£936.57 (ex. VAT)
● In Stock
Buy now
ⓘ Spread the cost with 0% finance options available at checkout.
Need help? Speak to our team on 0800 123 4567 or request a call back.
ⓘ F-Gas Compliance Required
This product is an air conditioning system and must be installed by an F-Gas registered engineer. We will require your engineer’s F-Gas certificate details before dispatch. Find out more about F-Gas regulations →
🚚
UK DeliveryFast & reliable
🛡
Manufacturer WarrantyGenuine product
◉
Expert HelpTalk to our UK team
✓
Secure CheckoutShop with confidence

Overview

The Lg multi split air conditioning inverter heat pump units make it possible to have multiple combinations of different indoor units with different capacities with the advantage of a space saving outdoor condensing unit. The latest Lg Inverter heat pump technology allows greater performance, lower sound levels, lower energy consumption and operates at optimum performance in a rapid and uniform manner until the temperature reaches its optimum set point. The DC Inverter multi split heat pump outdoor units are more efficient than their predecessor and Lg air conditioning’s renowned inverter technology is an innovative, energy-efficient feature that automatically adjusts the unit’s power to maintain room temperature across all the indoor units connected, rather than repeatedly starting and stopping the compressor. The patented Gold Fin™ process on the outdoor condensing unit is standard on the LG multi outdoor units and is an anti-corrosion coating that forms a protective shield against the elements to increase the product lifetime. As there is no need to install a large number of outdoor units, the outside aesthetics of the building are virtually unaffected, furthermore, the outdoor units offer great location flexibility to ease the installation.

Technical Specifications

OUTDOOR UNIT                                                                             MU2R15 UL0
Compressor                          Type Twin Rotary
Capacity * Cooling Min / Nom / Max       kW 0.9 / 4.1 / 4.7
Heating Min / Nom / Max       kW 1.0 / 4.7 / 5.4
Low Temperature Capacity  Heating -7°C Max                            kW 3.3
Power Input * Cooling Min / Nom / Max       kW 0.2 / 1.0 / 1.4
Heating Min / Nom / Max       kW 0.2 / 1.1 / 1.4
Running Current Cooling Min / Nom / Max       A 1.1 / 4.6 / 6.4
Heating Min / Nom / Max       A 1.1 / 4.9 / 6.6
EER 4.14
COP 4.38
SEER 8.50
SCOP 4.20
Pdesign (@-10°C) kW 4.10
Seasonal Energy Label         Cooling / Heating A+++ / A+
Annual Energy Consumption  Cooling / Heating 169 / 1,367
Airflow Rate                         Nom m3/min 28.2
Sound Pressure Cooling Nom                           dBA 48
Heating Nom                           dBA 51
Sound Power                        Cooling Max                            dBA 61
Dimensions                            W x H x D   mm 770 x 545 x 288



Net Weight Kg 36


Refrigerant

Type R32
Charge                                                    Kg 1.1
Additional Charge                                    g/m 20
GWP 675
t-CO2 eq 0.74
Operation Range (Outdoor) Cooling Min ~ Max                  °C DB -10 ~ 48
Heating Min ~ Max                  °C WB -18 ~ 18
Power Supply Ø / V / Hz 1 / 220-240 / 50
Power Supply Cable No. x mm2 3C x 2.5
Transmission Cable No. x mm2 4C x 0.75
Circuit Breaker A 15
Piping Length Total m 30
Piping Length per Branch Max                            m 20
Piping Elevation Difference IDU – ODU Max                            m 15
IDU – IDU Max                            m 7.5
Piping Connection Liquid                 mm (inch) x No. Ø6.35 (1/4) x 2
Gas                  mm (inch) x No. Ø9.52 (3/8) x 2

What’s Included

1 x Lg Air Conditioning Multi Room Heat Pump Inverter 2 Port 4Kw/14000Btu A+++ R32 220-240V~50Hz

Installation & F-Gas

These air conditioning units must be installed by an F-Gas qualified engineer. We can install the unit for you using our F-Gas Certified Engineers. Please note if you do not select our installation service we will not ship the unit until we have obtained evidence from you that you will have the unit installed by an F-Gas qualified engineer. This is a requirement of the Article 11 (5) EC/517/2014 on fluorinated greenhouse gases and The Fluorinated Greenhouse Gases Regulations 2015.
